Plug HD 240
Plug HD 240 is a high-quality industrial plug designed for reliable power connections in demanding environments. Manufactured by Holard, this 3-pin plug operates at 220–240V with a current rating of 16A. Constructed from durable plastic, it features an IP44 protection rating, ensuring resistance against dust and splashing water. The plug is suitable for various industrial applications, including manufacturing plants, workshops, and construction sites.
- Screw Terminals
- Straight
Technical Specification
| Ampere | 32 A |
|---|---|
| Poles | 5 P |
| Voltage | 400 V |
| Clock Position | 6 H |
| Hertz | 50-60 Hz |
| Connection Technology | Screw Terminals |
| Contact | Standard |
| Protection Type | IP 67 |
| Flange | 75x75 MM |
| Fixing Hole | 60x60 MM |
Drawing
| Code | HD 240 | |
|---|---|---|
| Rated Current (A) | 32 | |
| Poles | 5 | |
| Earth Contact Position | 6 H | |
| Dimension (MM) | A | 75 |
| B | 75 | |
| C | 60 | |
| D | 60 | |
| E | 5.5 | |
| F | 34 | |
| G | 101 | |
| I | 70 | |
| M | 29 | |
| K | 9 | |
| K1 | 2 | |
| Conductor Crossectional Area (MM9) Min To Max | 4 - 6 |
